链 号	抗拉载荷	节距						销轴直径	链   杆  参  数
	Q	80	100	125	160	200	250	d	R	S	C	C0	d1	T
	KN	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
MCL56	56	#	#	#				9.92	10	6	12	11	10	12
MCL80	80	#	#	#				11.905	12	7	14	13	12	14
MCL112	112		#	#	#			14.905	15	8	16.5	15	15	17
MCL160	160			#	#	#		17.905	18	10	18.5	17	18	20
MCL224	224				#	#	#	20.89	21	12	22	20	21	23
MCL315	315					#	#	24.89	25	14	26	24	25	27
MCL450	450						#	29.88	30	16	30	28	30	32
MCL630	630						#	35.88	36	20	32	30	36	40
MCL900	900							43.87	45	24	40	38	44	48
